- Size: 60
- Place of Origin: Shandong
- Brand Name: JANEOO
- Model Number: HZS60BE,HZS90BE,HZS120BE,HZS180BE,HZS240BE,HZS270BE
- Weight: 10000.000 kg
1、 Modular design, faster to assemble and disassemble, quick work site transfer, land layout flexible;
2、 Belt conveyor loading type, with stable performance; Equipped with aggregate middle storage hopper, with high productivity;
3、Powder weighing system adopt pull rod balance structure to ensure high measurement accuracy and strong anti-interference ability;
4、 Container type cladding, safe and convenient to assemble and disassemble, can use in cycle;
5、 High-end gas circuit and electric circuit configuration, with high reliability
- Size: 60
- Place of Origin: Shandong
- Brand Name: JANEOO
- Model Number: HZS60BE,HZS90BE,HZS120BE,HZS180BE,HZS240BE,HZS270BE
- Weight: 10000.000 kg
型号 Model | HZS60BE | HZS90BE | HZS120BE | HZS180BE | HZS240BE | HZS270BE | |||
理论生产率Theoretical productivity (m³/h) | 60 | 90 | 120 | 180 | 240 | 270 | |||
搅拌主机 Mixer | 型号Model | JS1000 | JS1500 | JS2000 | JS3000 | JS4000 | JS4500 | ||
驱动功率Driving power（Kw） | 2X18.5 | 2X30 | 2X37 | 2X55 | 2X75 | 2X75 | |||
出料容量Discharging capacity（L） | 1000 | 1500 | 2000 | 3000 | 4000 | 4500 | |||
骨料最大粒径（碎石/卵石mm）The Max. Diameter of the Aggregate( Gravel/Pebble)mm | ≤60/80 | ≤60/80 | ≤60/80 | ≤60/80 | ≤60/80 | ≤60/80 | |||
配料仓Aggregate Bin | 仓容积Aggregate bin volume (m³) | 3X12 | 3X12 | 4X20 | 4X20 | 4X30 | 4X30 | ||
皮带机输送能力 Belt conveyor capacity( t/h) | 200 | 300 | 400 | 600 | 800 | 800 | |||
称量范围及计量精度Weighing range & accuracy | 骨料Aggregate(kg) | 3X（1000±2%） | 3X（1500±2%） | 4X（2000±2%） | 4X（3000±2%） | 4X（4000±2%） | 4X（5000±2%） | ||
水泥Cement (kg) | 500±1% | 800±1% | 1000±1% | 1500±1% | 2000±1% | 2500±1% | |||
粉煤灰Fly ash (kg) | 200±1% | 300±1% | 400±1% | 600±1% | 800±1% | 900±1% | |||
水Water (kg) | 200±1% | 300±1% | 400±1% | 600±1% | 800±1% | 900±1% | |||
外加剂Additive (kg) | 20±1% | 30±1% | 40±1% | 60±1% | 80±1% | 90±1% | |||
卸料高度 Discharging height (m) | 4.0 | 4.0 | 4.2 | 4.2 | 4.2 | 4.2 | |||
整机功率 Total power consumption (KW) | 100 | 150 | 200 | 250 | 300 | 350 | |||
