- Place of Origin: shandong
- Brand Name: JANEOO
- Model Number: three axles truck
1. well designed,highly effcient, long serive time, high automobile performance
2. perform FEM analysis, use flexible connection,
3. split type front end,eliminate stress concentration,strengthen intergrated rigitidy,
4. high capacity feed hopper, fast, 3 points resilient mounting, impact resistance,
5. alloy wearalbe liner, long service time.
6. bilateral mechanical control and cab flexible shaft control: convenient,flexible, long service time
7. hydraulic pump, hydraulic motor and reducer use international famouse brand, reliable performance.
8. Shanghai Baosteel high wear-resistant material,B520JJ,long service time
9. blade adopts double logarithm spiral band,concave curve,rest rate less than 0.5%, far below national standard 2%
- Place of Origin: shandong
- Brand Name: JANEOO
- Model Number: three axles truck
规格 specification | JY306 | JY308 | JY309 | JY310 | JY312 | |
mixing drum performance | feed speed | ≥3 | ||||
discharge speed (m3/min) | ≤2 | |||||
rest rate (%) | ≤0.5 | |||||
mixing drum fixing angle(o) | 15 | 13 | 12 | 11.5 | 11 | |
slump range (mm) | 40-210 | |||||
water supply type | water supply mode | air pressure | ||||
water tank capacity (L) | 400 | |||||
hydraulic system | fydraulic pump,motor, gearbox | famous in the world | ||||
vehical chassis | driving type | 6X4 | ||||
wheel base | 3200 1350 | 3225 1350 | 3625 1350 | 3825 1350 | 4025 1350 | |
品牌brand | SINO TRUK, SHACMAN,FOTON,DFM,HINO |
