- Size: 31000*8000*16000
- Place of Origin: shandong
- Brand Name: JANEOO
- Model Number: HZN25SF/HZN40SF/HZN50SF/HZN75SF/HZS50SF/HZS75SF/HZS100SF/HZS150SF
- Weight: 50000.000 kg
Foundation Free Concrete Mixing Plant
1.Features:
1.Foundation free structure, the equipment can be installed and production after the work site is flat and hardened. Not only reduce the foundation construction cost, but also shorten the installation period.
2.Modular design, faster to assemble and disassemble, quick work site transfer.
3.Overall compact structure, less land occupation.
2. Product Specification:
Model | HZN25SF | HZN40SF | HZN50SF | HZN75SF | HZS50SF | HZS75SF | HZS100SF | HZS150SF | ||
Theoretical productivity (m³/h) | 25 | 40 | 50 | 75 | 50 | 75 | 100 | 150 | ||
Mixer | Model | JN500 | JN750 | JN1000 | JN1500 | JS1000 | JS1500 | JS2000 | JS3000 | |
Driving power(Kw) | 22 | 30 | 45 | 55 | 2X18.5 | 2X30 | 2X37 | 2X55 | ||
Discharging capacity(L) | 500 | 750 | 1000 | 1500 | 1000 | 1500 | 2000 | 3000 | ||
The Max. Diameter of the Aggregate( Gravel/Pebble)mm | ≤60/80 | ≤60/80 | ≤60/80 | ≤60/80 | ≤60/80 | ≤60/80 | ≤60/80 | ≤60/80 | ||
Aggregate Bin | Aggregate bin volume (m³) | 4X4 | 4X4 | 3X8 | 3X8 | 3X8 | 3X8 | 4X20 | 4X20 | |
Hoisting motor power (kW) | 5.5 | 7.5 | 18.5 | 22 | 18.5 | 22 | 30 | 45 | ||
Weighing range & accuracy | Aggregate (kg) | 1500±2% | 1500±2% | 3X(1000±2%) | 3X(1500±2%) | 3X(1000±2%) | 3X(1500±2%) | 4X(2000±2%) | 4X(3000±2%) | |
Cement (kg) | 300±1% | 500±1% | 500±1% | 800±1% | 500±1% | 800±1% | 1000±1% | 1500±1% | ||
Fly ash (kg) | --------- | -------- | 200±1% | 300±1% | 200±1% | 300±1% | 400±1% | 600±1% | ||
Water (kg) | 150±1% | 200±1% | 200±1% | 300±1% | 200±1% | 300±1% | 400±1% | 600±1% | ||
Additive (kg) | 20±1% | 20±1% | 20±1% | 30±1% | 20±1% | 30±1% | 40±1% | 60±1% | ||
Discharging height (m) | 4.0 | 4.0 | 4.0 | 4.0 | 4.0 | 4.0 | 4.0 | 4.0 | ||
Total power consumption (KW) | 40 | 50 | 100 | 150 | 100 | 150 | 200 | 250 |
Note:The above parameters are subject to change without prior notice, please refer to the actual product.
3. Application:
Foundation free concrete mixing plant is suitable for frequent relocation construction works, hydroelectric, roads, ports, bridges and other construction projects.
