Product Details
- Size: -
- Place of Origin: China
- Brand Name: JANEOO
- Model Number: HZZ50E
- Weight: 21000.000 kg
| Model | HZS25E | HZS40E | HZS50E | HZS75E | |
| Theoretical productivity(m³/h) | 25 | 40 | 50 | 75 | |
| (Mixer) | Model | JS500 | JS750 | JS1000 | JS1500 |
| Power(kW) | 18.5 | 30 | 2´18.5 | 2´30 | |
| (m³) Discharge capacity | 0.5 | 0.75 | 1 | 1.5 | |
| Max.Agg.size(Grave/pebble mm) | £60/80 | £60/80 | £60/80 | £60/80 | |
| Agg.bins | Volume (m³) | 4 | 4 | 8 | 8 |
| Hoisting motor power (kW) | 5.5 | 7.5 | 18.5 | 22 | |
| Scales capacity and accuracy | Aggregate (kg) | 1500±2% | 1500±2% | 2500±2% | 3000±2% |
| Cement (kg) | 300±1% | 500±1% | 500±1% | 800±1% | |
| Fly ash (kg) | — | — | 150±1% | 200±1% | |
| Water (kg) | 150±1% | 200±1% | 200±1% | 300±1% | |
| Additive (kg) | 20±1% | 20±1% | 20±1% | 30±1% | |
| Discharging height (m) | 4.0 | 4.0 | 4.0 | 4.0 | |
- Size: -
- Place of Origin: China
- Brand Name: JANEOO
- Model Number: HZZ50E
- Weight: 21000.000 kg
| Model | HZS25E | HZS40E | HZS50E | HZS75E | |
| Theoretical productivity(m³/h) | 25 | 40 | 50 | 75 | |
| (Mixer) | Model | JS500 | JS750 | JS1000 | JS1500 |
| Power(kW) | 18.5 | 30 | 2´18.5 | 2´30 | |
| (m³) Discharge capacity | 0.5 | 0.75 | 1 | 1.5 | |
| Max.Agg.size(Grave/pebble mm) | £60/80 | £60/80 | £60/80 | £60/80 | |
| Agg.bins | Volume (m³) | 4 | 4 | 8 | 8 |
| Hoisting motor power (kW) | 5.5 | 7.5 | 18.5 | 22 | |
| Scales capacity and accuracy | Aggregate (kg) | 1500±2% | 1500±2% | 2500±2% | 3000±2% |
| Cement (kg) | 300±1% | 500±1% | 500±1% | 800±1% | |
| Fly ash (kg) | — | — | 150±1% | 200±1% | |
| Water (kg) | 150±1% | 200±1% | 200±1% | 300±1% | |
| Additive (kg) | 20±1% | 20±1% | 20±1% | 30±1% | |
| Discharging height (m) | 4.0 | 4.0 | 4.0 | 4.0 | |
